1.Product Introduction
Single mode and multi mode SC fiber optic patch cables, SC-LC, SC-ST, SC-FC, SC-MU, SC-MTRJ, SC-E2000, 9/125μm, 50/125μm, 62.5/125μm, SM, MM, simplex, duplex, UPC, APC, PC. Customized design cables are available.
The SC fiber optic patch cord is one of the earliest type and one of the most commonly used fiber optic cable, it is convenient to use and cost saving, It is the most cheapest type fiber optic patch cable. SC fiber patch is widely uesed in fiber optic networks. SC fiber patch cable is with zirconia sleeve and plastic housing.
2.Features
♦Superior performance and high reliability
♦Many connector types available
♦Low insertion loss and high return loss
♦Accomplish the movement connect of optic fiber transfer
3.Application
♦ For room equipment internal link
♦ For ODF internal link
4.Technical Specifications
| Item | SM | MM |
| Link Type | FC/PC | FC/UPC | FC/APC | FC/PC |
| SC/PC | SC/UPC | SC/APC | SC/PC |
| ST/PC | ST/UPC | | ST/PC |
| LC/PC | LC/UPC | | LC/PC |
| MU/PC | MU/UPC | | MU/PC |
| Return Loss | ≥45dB | ≥50dB | ≥60dB | ≥35dB |
| Insertion Loss | ≤0.2dB |
| Operating Temperature | -40°C ~ +80°C |
| Repeatability | ≤0.1dB |
| Interchangeability | ≤0.2dB |
| Insertion and Pull Times | 1000 |
FAQ
Q1: How the warranty for products ?
A: 10 years,and maintance for whole life
Q2: Can we make OEM for products?
A: Yes, we can print your logo or label on the products or on the box.
Q3: Can you provide free samples ?
A: Some of low value samples can be free for you, but you need pay for the shipping cost.
Q4: How can you guarentee the quality ?
A: Build on our perfect quality management system, all of our products were 100% tested before the shipment.
Q5: What is your delivery time ?
A: Generally, sample: 3~5 working days. formal order: 7-10 working days.
Q6: What's your payment terms ?
A: We accept T/T, Western Union, Money Gram, Paypal.
For samples: 100% payment. Formal order: 30% as deposit, 70% balance payment before shipment
